Rotex - 51424-6-2R-M6+24V-DC-37-01
Please contact us to request a price quote for Rotex - 51424-6-2R-M6+24V-DC-37-01, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Rotex |
|---|---|
| Part number | 51424-6-2R-M6+24V-DC-37-01 |
| Inner Code | 4767855 |
| Description | Valve |
| Technical specification | "5/2, 3/2 CONVERTIBLE NAMUR SOLENOID VALVE; TYPE 5 PORT 2 POSITION, 3 PORT 2 POSITION CONVERTIBLE; OPERATION: INTERNAL PILOT OPERATED POPPET TYPE NAMUR PORTEDORIFICE: 6mm; PORT CONNECTION- NPT (F); MANUAL OVERRIDE: FOR PRESSURE RANGE 2-10 BAR, PROVIDED WITH PUSH & TURN TYPE; SEALS & SEAT: THE VALVE IS PROVIDED WITH NBR SEALS & SEAT MATERIAL; ELECTRICAL INSULATION: THE SOLENOID IS HAVING CLASS F INSULATION; BODY MATERIAL: ALUMINIUM Al, Br, SS. SOLENOID 24VDC: EXD IIC T6 EXPLOSION PROOF, WITH JUNCTION BOX, POWER 8W TAG: U-113; |
