Rexroth - R911335596 / HCS01.1E-W0008-A-03-B-ET-EC-NN-L3-NN-FW
Please contact us to request a price quote for Rexroth - R911335596 / HCS01.1E-W0008-A-03-B-ET-EC-NN-L3-NN-FW, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Rexroth |
|---|---|
| Part number | R911335596 / HCS01.1E-W0008-A-03-B-ET-EC-NN-L3-NN-FW |
| Inner Code | 4650154 |
| Description | DRIVER |
| Technical specification | Control panel With standard operating panel, firmware must be ordered separately Width 50 mm Continuous power (without choke) 0.86 kW Interface encoder 1 Multi-encoder interface Height 220 mm Switching frequency / max. output frequency (@16kHz) 0-1600 Hz Maximum current 8 A International protection code IP20 Maximum power (without choke) 2.58 kW Cooling type Internal air cooling Power supply voltage (3 AC) 200-500 V Switching frequency / max. output frequency (@8kHz) 0-800 Hz Output voltage 3 x AC 0 ... 500 V Switching frequency / max. output frequency (@12kHz) 0-1200 Hz Control unit power BASIC Nominal mains frequency 50-60 Hz Type code extension HCS01.1E-W0008-A-03-B-ET-EC-NN-L3-NN-FW Safety function Safe Torque Off (STO) Continuous current 2.7 A Switching frequency / max. output frequency (@4kHz) 0-400 Hz Interface encoder 2 Not defined Predefined communication protocol MultiEthernet Depth 215 mm |
