Rexroth - R900595683 / 5-4WE10R3X/CG24N9K4
Please contact us to request a price quote for Rexroth - R900595683 / 5-4WE10R3X/CG24N9K4, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Rexroth |
|---|---|
| Part number | R900595683 / 5-4WE10R3X/CG24N9K4 |
| Inner Code | 5014128 |
| Description | Directional valve |
| Technical specification | Series / Family WE series - size 10 (5-chamber version) / component series 3X Valve Function 4/3-way (4 ports / 3 positions), Double solenoid, Monostable Max. Flow 150L/min 40gallons/min Hydraulic Fluid Temperature Range −30°C…+80°C −22°F…+176°F Ambient Temperature Range −30°C…+50°C −22°F…+122°F Reset Method Mechanical Spring Manual Override Flush / Concealed Solenoid High-Power Wet-Pin with Detachable Coil Seal Material NBR Connection Type 3-pin DIN connector (43650) Mounting Mode Porting pattern according to ISO 4401-05-04-0-05 Current Consumption 2A (nominal hold current) Control Voltage (DC) 24Vdc Diagram circuit diagram R Protection Class IP65 |
