Regloplas - P140M/8/SM72/SK/RT100
Please contact us to request a price quote for Regloplas - P140M/8/SM72/SK/RT100, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Regloplas |
|---|---|
| Part number | P140M/8/SM72/SK/RT100 |
| Inner Code | 1804252 |
| Description | Single Zone Temperature Control Unit |
| Technical specification | o Indirect Cooling – advanced technology for facilities with marginal water conditions. o Automatic water refill and automatic fluid level control. o All components exposed to water are made of non-ferrous materials. o Leak free magnetically coupled centrifugal pump for lower maintenance and lower operating costs. o Solid State Relays o The 3.5” TFT display shows all active functions and has a selectable language program. o Outlet Temperature – Maximum 285º F. o Number of Independent Zones 1 o Heat Transfer Fluid Water o Filling Capacity of Unit .7 Gallons o Expansion/Reservoir Capacity – Maximum .3 Gallons o Heating Capacity 8kW o Cooling Capacity at Outlet Temperature – Maximum 55kW @ 265º F. o Pump Model / HP SM72 / 1.5 HP o Flow Rate – Maximum 16 GPM o Outlet Pressure – Maximum 87 PSI o Approx. System PSI 153.5 PSI o Controller Model RT100 o Solid State Relays Standard o Fill Pump – Booster Standard o Measuring Mode PT-100 o Operating Voltage 480V/3/60 o Control Voltage 230V/1/60 o Power Requirements – Maximum 20 Amps @ 480V o Connections - Process Outlet/Inlet G ¾” o Connections - Cooling Outlet/Inlet G ½” o Noise Level <70db o Dimensions (W/H/D) – Weight 13”/30”/35” -- 200 Lbs. |
| Weight: | 113.39 |
