Regloplas - 300S/6/FM25/1K-RT100
Please contact us to request a price quote for Regloplas - 300S/6/FM25/1K-RT100, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Regloplas |
|---|---|
| Part number | 300S/6/FM25/1K-RT100 |
| Inner Code | 104863 |
| Technical specification | type 1-circuit device, semi-open system flow temperature max. 300 °C Heat carrier oil Capacity: 6 litres Max. expansion area 7 litres Heating capacity: 6 kW Cooling output 70 kW at flow temperature 280 °C at cooling water temperature 20 °C at flow rate per circuit 20 l/min Pump type FM25 — magnetic coupling pump Flow rate max. 45 l/min Pressure max. 7.0 bar Power consumption 1.0 kW Control unit RT100 Measurement Type Pt100 ports Voltage: 400V/50Hz/3PE Fout/return G ½” Cooling water network G ½” Mains water pressure 2-6 bar Total power consumption 11.5 A Ambient temperature max. 40 °C Dimensions W/H/D 322/758/909 mm Color Grey, RAL 9006/7016 Continuous sound pressure level <70 db (A) Standard equipment functions • RT100 control system with PID control behavior * Electrical part • Electrical control according to IEC standards • Degree of protection IP 54 • Safety thermostat as protection against overheating • Solid state relays for wear-free switching operations • Flow monitoring to protect against dry running and oil overheating • Two-stage level monitoring • Includes main switch • USB data logger for process logging • Recording of process data on USB stick • Saving as a CSV file * Mechanics • Leak-free magnetic coupling pump • Bypass for internal oil circulation in case of insufficient flow • Separate expansion tank prevents the leakage of oil vapors • Pressure gauge in flow and return • Dirt filter in the water mains connection • Check valve in the cooling water drain • Mounted on lockable transport rollers |
| Weight: | 87.089735 |
