Regloplas - 300LD/20KW/FM65/1K/RT200
Please contact us to request a price quote for Regloplas - 300LD/20KW/FM65/1K/RT200, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Regloplas |
|---|---|
| Part number | 300LD/20KW/FM65/1K/RT200 |
| Inner Code | 5058387 |
| Description | Dual Zone Temperature Control Unit for the thermal control of die cast dies, rubber and plastic molds, extruders, rollers, vessels and other consumers. |
| Technical specification | Standard Features: o Magnetic Coupled Centrifugal Pump for leak free operation: lower maintenance costs, lower operating costs and less downtime. o Forced Flow Oil System for reduced oil degradation and a tighter temperature control band. o Stainless Steel Reservoir Tank o Controller with 3.5” TFT display with selectable languages and USB Interface Technical Data (Per Zone*): o Outlet Temperature – Maximum* 570° F o Number of Independent Zones 2 o Heat Transfer Fluid Thermal Oil o Filling Capacity of Unit 6.3 Gallons o Expansion Tank / Reservoir Capacity – Stainless Steel Construction 5.3 Gallons o Heating Capacity* 20kW o Cooling Capacity at Outlet Temperature – Maximum* 160kW @ 535º F. o Pump Model / HP* FM65 / 4 HP o Flow Rate – Maximum* 23 GPM o Outlet Pressure – Maximum* 145 PSI o Controller Model* RT200 o Solid State Relays* Standard o Second Level Switch in Reservoir Standard o Measuring Mode* PT-100 o Operating Voltage 480V/3/60 o Control Voltage 230V/1/60 o Power Requirements – Maximum 62 Amps @ 480V o Connections – Process - Oil Outlet/Inlet G 3/4” o Connections – Cooling - Water Outlet/Inlet G 3/4” o Noise Level <70db o Dimensions (W/H/D) – Weight 21”/53”/56” -- 805 Lbs. o Power cord Customer supplied Required options to duplicate unit #1251-103905-23-0114 (NOT included in base price, prices are for both zones): A. 400v / 50 / 3 Included B. Heater - 40kW / +31 Amps C. MP2003 – Cascade Control Inlet Sn3 – S – M - L D. MP2050 – Interface – Profibus DP – Sub D9 E. MP2110 – Flow Meter – F1000 – Manual Calibration |
