Regloplas - 150smart
Please contact us to request a price quote for Regloplas - 150smart, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Regloplas |
|---|---|
| Part number | 150smart |
| Inner Code | 595887 |
| Description | Single Zone Temperature Control Unit |
| Technical specification | Standard Features: Heavy duty centrifugal pump Indirect cooling - advanced technology for plants with marginal water conditions Solid State Relays Acoustic Alarm Automatic fluid level control Automatic pump rotation correction Leak-stop operation and drainage of the consumer Non-ferrous components in water system RT70 Controller with 3.5” TFT Display Technical Data: Outlet Temperature – Maximum 300 F. Number of Independent Zones 1 Heat Transfer Fluid Thermal Oil Filling Capacity of Unit 3.2 Gallons Expansion/Reservoir Capacity – Maximum 1.1 Gallon Heating Capacity 6kW Cooling Capacity at Outlet Temperature – Maximum 28kW @ 285 F. Pump type / HP TP20 / .75 HP Flow Rate – Maximum 16 GPM Outlet Pressure – Maximum 55 PSI Controller Model RT-70 Relays Solid State Measuring Mode PT-100 Operating Voltage 480V/3/60 Control Voltage 24VDC Power Requirements – Maximum 9 Amps @ 480V Connections - Process Outlet/Inlet G 1/2” Connections - Cooling Outlet/Inlet G 1/2” Noise Level <70db Dimension (W/H/D) – Weight 8”/22”/23” -- 110 Lbs. |
| Weight: | 1 |
