Fuji - MID2-65/16F/ST-HG-ML/HC-ST PAO SL200
Please contact us to request a price quote for Fuji - MID2-65/16F/ST-HG-ML/HC-ST PAO SL200 , or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Fuji |
|---|---|
| Part number | MID2-65/16F/ST-HG-ML/HC-ST PAO SL200 |
| Inner Code | 583796 |
| Description | MAGNETOFLOW Flowmeter |
| Technical specification | Detector Type: Type 2 Flanges : DIN 2501 ST.37 Pressure : PN16 Nominal Diameter: DN65 Measuring Range : depent of pipe diameter Electrode Material : HASTELLOY C Pipe material: Stainless Steel 1.4571 Liner Material: Hard Rubber Fluid Temperature : 80 celcious Housing: ST. 37 Welded Accuracy: < 0.25% of value Type of protection: IP65 Acc. Din 40050 Instalation Length: depent of pipe size Min Conductivity: >0.5 Micro S/cm Mounting: in each position Amplifier: Yes type primo advanced Power Supply : 230 VAC , 50/60 Hz Housing : Cast Aluminium Flow Direction : Bi Directional 2 separate Totalizers Analog Output: 0/4-20mA <600 Ohm Impulse Length: Configurable Low flow cut out : 0-10% Zero point Stability: Automatic Correction Galvanic Separation : yes all outputs min 500V Short Circuit Proof Connection: 3PG 13.5 Ambient Temp. : -20 to 60 C Mounting : Mounted on detector Display: 4 Lines of 16 Digits 1 min. 1max. Configurable |
| Weight: | 1 |
