Dixell - XH240K
Please contact us to request a price quote for Dixell - XH240K, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Dixell |
|---|---|
| Part number | XH240K |
| Inner Code | 1860558 |
| Description | Temperature and humidity controller |
| Technical specification | Housing: open board; Case: 77x102mm Mounting: panel with two screws. 3x2mm. Connections: Screw terminal block 2,5 mm2 heat-resistant wiring and 6,3mm Faston Power supply: 230Vac 10%; Power absorption: 7VA max. Inputs: 1 NTC probe + 4÷20mA probe Digital input: 1 free voltage Relay outputs: compressor: relay SPST 20(8) A, 250Vac heather: relay SPST 16(6) A, 250Vac fans: relay SPST 8(3) A, 250Vac humidifier: relay SPST 8(3) A, 250Vac Data storing: on the non-volatile memory (EEPROM). Kind of action: 1B.; Pollution grade: normal; Software class: A. Operating temperature: 0÷60 °C.; Storage temperature: -25÷60 °C. Relative humidity: 2085% (no condensing) Measuring and regulation range: NTC probe: -40÷110°C (-58÷230°F) Resolution: 0,1 °C or 1°C or 1 °F (selectable). Accuracy (ambient temp. 25°C): ±0,5 °C ±1 digit |
| Weight: | 1 |
