Dixell - IC121C-11102 FW 3.2 24Vac
Please contact us to request a price quote for Dixell - IC121C-11102 FW 3.2 24Vac, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Dixell |
|---|---|
| Part number | IC121C-11102 FW 3.2 24Vac |
| Inner Code | 531284 |
| Description | Multifunction Controller |
| Technical specification | Overviews/Screen: double with icons Power supply 12, 24 V AC/DC PB1 probe inputs: NTC - Pb2: NTC - Pb3: NTC, 4÷20 mA, 0÷5 V configurable - Pb4: NTC, configurable DI HP digital inputs: present - LP: present - No. 4: configurable RL1 compressor relay outputs: 8A - RL2:8A configurable - RL3:8A configurable - RL4:8A configurable - RL5:8A configurable - RL5:8A configurable Other outputsDirect access key/programming tool kit/TTL output: present - Analog: 4÷20 mA/10 V optional - Signal for fan speed control: PWM - Voltage output for external relay: 12 V CC-40 mA max. OtherRemote screen output: 1 x VICX610 - Real-time clock: optional - Acoustic indicator: optional 4-digit red LED display, 8.5 mm high 4-digit yellow LED, 7.5 mm high Data storage in non-volatile memory (EEPROM) Operating temperature-10÷60 °C Storage temperature-30÷85 °C Relative humidity20÷85% (without condensation) Measurement and adjustment range/pressure sensor: 0÷50 bar; NTC probe: -50÷110 °C Resolution 0.1 °C, 0.1 bar Accuracy (at room temperature) ±0.8°C |
| Weight: | 1 |
