MAXITOP LW C 40 ZD / 556310 Bamo

Manufacturer	Bamo
Part number	MAXITOP LW C 40 ZD / 556310
Inner Code	4528514
Description	Compact - leakage probe with integrated transmitter,
Custom code	90261029
Technical specification	Compact - leakage probe with integrated transmitter, capacitive-high-frequency media detection, power supply: 15 - 27 V DC, Output: Relay, potential-free, opens in case of alarm max. 50 V AC/DC/0.5 A/10 VA, Transducer material: PE-HD, diameter 40 mm, cable material: PVC, cable length 6 meters, Connection head made of PBT, degree of protection IP65 with adjustable d63 cap for DN50, with connection for external test button Item no. 556310

Bistable switch

ELECTRODE (FOR BSM 501 4-250 V 1M A - 3A LEVEL CONTROL SWITCH)

Tige lg 1000mm Tige Inox 316L, Ø4mm, Longueur 1000mm

LW CN SDR 4 Obsolete!! Replaced by MAXIMAT LW CX SDR 4

Leak probe for double wall pipes Compact design with integrated transducer and integrated reference electrode DIBt approval Z-65.40-316 Power supply 24 V DC, Material pickup HDPE, Sealing O-ring EPDM Sensor and reference electrode of glassy carbon

MEMBRANE AFFLEURANTE

PRESSURE SENSORS 4-20ma output connection 1 inch 0 ..... pressure 2.5bar

PP-Schwimmer S40 / d42 x 132 mm

PP float S40 / d42 x 132 mm for pipe d50 x 2.4 mm Article no. 570084

SHR C S G

Transmitter for overfill and leakage sensors WHG approved for MAXIMAT-overfill prevention and MAXIMAT leakage probes Housing protection IP 40, for DIN-rail, 2 changeover outputs, error signaling, Supply voltage 230 V AC Item No. 555600

TRANSMITTERS FOR SENSORS

556700 (MAXIMAT LW CX 40 K)

Compact leak detector

BRK60/32

Bistabies Reedkontakt

520834 (SS2 WA 5)

Float switche

523020 / ACS-20

Schwimmerschalter in Birnenform

BSM 501 (585100)

Level switches with micro-switch

CN46254, obsolete, replacement CX 40 K 4 N F40 4 L
