Bamo - KFS-M40 /713-101DL2000B6A5
Please contact us to request a price quote for Bamo - KFS-M40 /713-101DL2000B6A5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Technical information
| Manufacturer | Bamo |
|---|---|
| Part number | KFS-M40 /713-101DL2000B6A5 |
| Inner Code | 4874328 |
| Description | Flow Indicator |
| Custom code | 90261081 |
| Technical specification | KFS-M40 PN 40 DN 150 flap type flow meter U 10 - 110 m³/h H2O direction of flow: to be mentioned with the order inner diameter: to be mentioned with the order installation length: 50 mm pmax: 40 bar at 20° C applicable for PN 25/40 ring: S355 inner parts: 1.4571 standard gasket: SIL 4400 indicator casing M40: aluminium painted protection class: IP67 pointer: Alu painted scale: Alu coated pane: glass corrosion protection: Epoxy powder coating, traffic blue (RAL 5017) glossy corrosion class: C3 The device is designed in accordance with the PED for use in Category 2 and is also suitable for use in Category 1 and Section 4.3 |
